China Best Products Chinese tractor Jinma Series 18-45 HP Farming Tractor
| Model | HHJM-454 | |||||||||
| Drive type | 4WD | |||||||||
| Overall Dimensions (mm) |
Total length | 3825 | ||||||||
| Total width | 1625 | |||||||||
| Total height | 2065 | |||||||||
| Wheel Base(mm) | 1943 | |||||||||
| Wheel
tread (mm) |
Front | 1300 | ||||||||
| Rear | 1300-1600 | |||||||||
| Min ground clearance(mm) | 325 | |||||||||
| Farming ground clearance(mm) | 375 | |||||||||
| Tractor
weight (kg) |
Structural weight | 1952 | ||||||||
| Min use weight | 2116 | |||||||||
| Engine | Model | SL3105ABT | ||||||||
| Type | 3-Cylinder,vertical,water cooled,4-stroke | |||||||||
| Power/Rated speed (kW/r/min) |
33.1/2200 | |||||||||
| Starting type | Electric start | |||||||||
| Displacement(L) | 3.039 | |||||||||
| Tire | Front | 8.3-20 | ||||||||
| Rear | 12.4-28 | |||||||||
| Turning
radius (m) |
With one-side braking | 3.5¡À0.3 | ||||||||
| Without braking | 4.1¡À0.3 | |||||||||
| Clutch | Single stage or Dual stage | |||||||||
| Brake | Oil bathing ,two disc brake | |||||||||
| Gearbox | Two-shaft,meshed gear 4x(2+1) combine or Creeper can be chosen | |||||||||
| Steering type | Mechanical steering or Hydraulic steering | |||||||||
| Lifting linkage | Rear 3-point hitch, category 1 | |||||||||
| Rated traction force(N) | 11700 | |||||||||
| Plowing depth control | Draft and position combined,float dominate | |||||||||
| Speed
(km/h) |
Forward |
Gear
|
1st | 2nd | 3rd | 4th | 5th | 6th | 7th | 8th |
|
4x(2+1)
|
2.145 | 3.150 | 5.122 | 6.725 | 9.632 | 14.150 | 23.003 | 30.203 | ||
|
Creeper
|
0.321 | 0.472 | 0.767 | 1.007 | 1.442 | 2.118 | 3.443 | 4.520 | ||
| Reverse |
Gear
|
1st |
2nd | 3rd | 4th | |||||
|
4x(2+1)
|
3.182 | 4.675 | 7.600 | 9.979 | ||||||
|
Creeper
|
0.476 | 0.700 | 1.138 | 1.494 | ||||||
| PTO | Type | Nonindependent or semi-independent | ||||||||
| Speed(r/min) | Choose any two of 540,720,1000 | |||||||||
